Gasoline Generators
K E Y F E A T U R E S
- Safety ensured, separated operation sections for low voltage and high voltage.
-
Reliability ensured: 500 hrs durability test, 100% offline test, 3% lower failure rate, ABR and FSA.
-
Using life ensured, reinforced frame, optimized cylinder head cover and fan cover.
- User friendly: Single/double handlebar design.
- Apperance: Solid logo and PVC decal design.
- Robot frame welding process ensures good consistency.
- Special muffler chamber design, lower noise.
- Patent exterior design, compact structure.
P R O D U C T S P E C I F I C A T I O N S
| Model |
LC1600-JS |
| Engine Model |
LC148F-2 |
| Engine Type |
single cylinder, air-cooled, 4-stroke, OHV |
| Output Power (kW/Rpm) |
1.65 / 3600 |
| Bore x Stroke (mm) |
68 x 43 |
| Displacement (cc) |
80 |
| Compression Ratio |
8.5 : 1 |
| Engine Oil Capacity (L) |
0.35 |
| Fuel Tank Capacity (L) |
9.6 |
| Continuing Time (H) |
11 |
| Rated Frequency (Hz) |
60 |
| Rated Voltage (V) |
220 |
| Rated Output (kW) |
0.85 |
| Starting Output (kW) |
1 |
| Power Factor |
1 |
| Starting System |
recoil |
| Ignition System |
Transistorized magneto ignition |
| Noise db(A) |
≤ 68.5 |
| Net Weight (kg) |
26 |
| Product Dimension (mm) |
475 x 369 x 415 |
| Products Characteristics |
- With Loncin commercial engine, low vibration, over 500 hrs durability test, stable, reliable and powerful.
-
Compact and easy-operation design.
-
Precise ignition control. Engine speed control system against different load.
|
