General Purpose Engines
K E Y F E A T U R E S
- Large capacity muffler design, ensures a lower noise level.
- Easy starting, starts within 3 attempts.
- With low oil alert function, auto-stop when oil level is low.
- Optimized combustion chamber and air vent, to improve burning efficiency.
- Lower fuel consumption and exhaust emission.
P R O D U C T S P E C I F I C A T I O N S
| Model |
LC170F-4 Marine |
| Engine Type |
single cylinder, air-cooled, 4-stroke, OHV |
| Displacement (cc) |
212 |
| Net Power (kW/3600r/min) |
5.5 (over 4600RPM) |
| Bore x Stroke (mm) |
70 x 55 |
| Net Torque (Nm/r/min) |
13.5 / 3000 |
| Starting System |
recoil |
| Lubrication System |
splash |
| Air Filter |
without element |
| Engine Oil Capacity (L) |
0.6 |
| Fuel Tank Capacity (L) |
3 |
| Net Weight (kg) |
15 |
| Product Dimension (mm) |
330 x 375 x 336 |
| Products Characteristics |
- Special designed marine engine.
-
Normal speed with over 500 hrs. Long-time durability.
- High speed CDI. Special designed air cleaner and governor system. High durability bearing, camshaft, cylinder head, piston set.
|
